RM-3003

3U Rackmount Chassis

Links to Related Products

RM-1002
RM-1003
RM-1004
RM-1021
RM-1042
RM-1044
RM-1044B
RM-13310
RM-13604
RM-238A
RM-2001
RM-2003
RM-2004
RM-2005
RM-2006
RM-2081
RM-2081A
RM-2081B
RM-2082AH
RM-2082AN
RM-2121B
RM-2142A
RM-23808
RM-23524
RM-23824
RM-25324
RM-3001
RM-3161B
IC-610
RM-4001
RM-4002
RM-4007
RM-4081
RM-4081E
RM-423
RM-4241B
RM-4262A
RM-4382A
RM-6502A
RM-6622A
SpecificationPrevious Page
Model Name RM-3003
Type 3U Rack Mount
Mother Board Form Factor Upto ATX - 12" * 9.6"
Dimension (D*W*H) 303 * 435 * 133 mm
Carton Size 850 * 600 * 260 mm

    Opt1 Opt2 Opt3
Drive Bays Ext. 5.25"
Int. 3.5" "
Int. 2.5"
   1
   3
   -
  1
   2
   1		      -
   2
   3
Front I/O Ports 2 * USB 3.0
Cooling Fans Standard 4 * 6 cm fan
Optional 3 * 6 cm fan
Rackmount Kit Optional
Color Black
Compatible SMPS FSP300-60GHC
FSP400-60GHC
FSP500-60GHC
FSP700-80PSA
Special Features I/O Front or Standard Rackmount
Wallmount Compatible
Net Weight 5.25 KG
Download PDF File
