RM-25324

2U Rackmount Chassis

Links to Related Products

RM-1002
RM-1003
RM-1004
RM-1021
RM-1042
RM-1044
RM-1044B
RM-13310
RM-13604
RM-238A
RM-2001
RM-2003
RM-2004
RM-2005
RM-2006
RM-2081
RM-2081A
RM-2081B
RM-2082AH
RM-2082AN
RM-2121B
RM-2142A
RM-23808
RM-23524
RM-23824
RM-3001
RM-3003
RM-3161B
IC-610
RM-4001
RM-4002
RM-4007
RM-4081
RM-4081E
RM-423
RM-4241B
RM-4262A
RM-4382A
RM-6502A
RM-6622A
SpecificationPrevious Page
Model Name RM-25324
Type 2U Rack Mount
Mother Board Form Factor ATX - 12" * 9.6"
Dimension (D*W*H) 880 * 438 * 87 mm
Carton Size 1120 * 590 * 240 mm
Drive Bays



   Opt1 Opt2 Opt3
3.5" SAS / SATA Hot Swap
   24
    24   24
Rear 2.5" SAS / SATA Hotswap    0    2    0
Rear 2.5" NVME Hotswap
    0    0    2
Front I/O Ports 2 * USB 3.0
Cooling Fans 6 * 6 cm Hotswappable fans
Backplane Connector Mini SAS HD (SFF 8643) with 12G Expander Backplane
Rear Window Low Profile
Color Black / Silver
Compatible SMPS FSP800-50FS
FSP1200-50FS
GW-CRPS1600D
Net Weight 21 KG
Download PDF File
