SpecificationPrevious Page
Model Name RM-1042
Type 1U Rack Mount
Mother Board Form Factor Mini ITX - 17 cm * 17 cm
Dimension (D*W*H) 400 * 435 * 45 mm
Carton Size (D*W*H) 570 * 560 * 150 mm
Drive Bays
Slim Optical Drive Bay
3.5" / 2.5" Hot Swap
2.5" Int. SATA		 Opt1
  1
  4
  2
Opt2
  0
  4
  3

Backplane Connector Discrete SATA
Cooling Fans Standard 3 * 4 cm fan
Front I/O Ports 1 * USB 3.0 + 1 * USB 2.0 or 2 * USB 2.0
Rackmount Kit Standard
Color Black / Silver
Compatible SMPS FLEX-200W
FSP250-50FEB
FSP850-50FGPH3
FSP500-50FDB
Net Weight 10 KG
Compatible Riser Cards 1U Riser Cards
