SpecificationPrevious Page |
||||||||
|---|---|---|---|---|---|---|---|---|
| Model Name | TW-125 | |||||||
| Type | Tower, Rack Convertible | |||||||
| Mother Board Form Factor | Ext. ATX 12" * 13" | |||||||
| Dimension (D*W*H) | 580 * 200 * 445 mm | |||||||
| Carton Size (D*W*H) | 740 * 325 * 570 mm | |||||||
| Expansion Slots | 8 (Can house 4 * double width GPU) | |||||||
| Drive Bays | Ext. 5.25" Int. 3.5" Int. 2.5" |
1 Upto 6 4 |
||||||
| Cooling Fans | Standard 2 * 12 cm fan Optional 1 * 12 cm (Normal & High speed), 2 * 8 cm Ext. Rear Cooling Kit for GPU |
|||||||
| Front I/O Ports | 2 * USB 3.0 / 2.0, 1* USB-C | |||||||
| Audio Connector | HD Audio | |||||||
| Color | Black | |||||||
| Compatible SMPS | FSP700-80PSA FSP1000-50ABB HPT2-1200M FSP2000-52AGPBI FSP550-50FS FSP800-50FS FSP1200-50FS GW-CPRS1600D GW-CPRS2000D GW-CPRS2700D |
|||||||
| Net Weight | 12 KG | |||||||
| Special Features | Rack convertible Intrusion Switch 240 / 360 Liquid Cooler Compatible |
|||||||
| Download PDF File | ||||||||
