Specification Previous Page |
|||||||||
|---|---|---|---|---|---|---|---|---|---|
| Features | |||||||||
| Host Adapter Architecture | Operating System Support | ||||||||
 |
PCI-Express 2.0x1 | |
Microsoft Windows 7-32/64 bit | ||||||
|
SATA 6Gb/s Controller | |
Microsoft Windows Vista, Windows 2008, Windows 2003 | ||||||
|
2 Internal SATA Port | |
Free BSD | ||||||
|
Marvell 88SE9130 chipset | Package Contents | |||||||
|
Low Profile | |
Controller Card | ||||||
| Maintenance and Management Settings | |
Software CD (User Manual and Management Utility) | |||||||
|
Hot key (ctrl+m) boot utility | |
Quick Installation Guide | ||||||
|
Hot swap and hot plug capability | |
Low profile bracket | ||||||
|
Power Efficient - Going Green Saves Green | |
Supplied with 2 SATA Cables | ||||||
| Monitoring Tools | Operating Voltage | ||||||||
|
Hard disk LED | |
PCI-Express : 3.3V/12V | ||||||
| Virtual Disk Support | |
Power: 1W max / 3W max | |||||||
|
Capacity Mode (Best Performance) | ||||||||
|
Safe Mode (Performance and Fault Tolerance) | ||||||||
| Management Suite | |||||||||
|
Web based management interface (MSU) | ||||||||
| Download PDF File | |||||||||
